T-Matic-5020

This bagger is an easy to use and setup multilanguage user friendly automatic side sealer especially developed for the packing and sealing of single or pile of textile products.

Details

This automatic sealer works with a continuous side sealer and a longitudinal intermittent sealing system that has indisputable advantages :

  • Esthetical sealing for a clean presentation
  • Unlimited productslenght that can be packed
  • Significant increase in production capacity
  • Less waste of film, resulting in lower costs

Features

  • Alternate longitudinal sealing system with a continuous vertical seal
  • PTFE coated horizontal sealing bar
  • Inverter and encoder controlled
  • Automatic adjustment of the center seal
  • Flexmode control sytem with:
    • Alpha numeric LCD control panel
    • Panel PC and 7” full colour touchscreen display
    • 32-bit microprocessor
    • Each motor equipped with an inverter
    • In/out control modules for digital, analog
    • Input/output and thermo couple- reading
    • Control for series
  • Memory capacity for 40 different operating programs
  • Easy film insertion and convoying system
  • Kissing belts
  • Storage / readout of process statistics (counter,measurements of pack length, real time output, machine performance, control of irregular packs)
  • Automatic control of the sealing bar height
  • Conveyor speed electronically adjustable
  • Single pack/ multi-pack mode
  • Adjustable sealing time
  • The seal temperature is dual adjustable (for both sealers)
  • Faulty packs detection

Technical specificationsmetricUS
Machine sizes (LxWxHJ)2180x1545x1655mm86x61x65in
Seal dimensions500mm / Length unlimited20in/length unlimited
Max. product height200mm8in
Max. film reel width600mm24in
Max. film reel diameter350mm14in
Conveyor speed10-30m/min31-99ft/min
Production capacity600-2400 pack/hour
Compressed air6 bar/0,6Nl/P87 psi / 3.5 cu ft/s
Power supply380-415V/3ph/50-60Hz
Machine weight720kg1587lb
Max. film reel width600mm24in
Max. film reel diameter350mm14in
Production capacity600-2400 packs/hour
